Megagen Z Series Generators

SPEC SHEET REQUEST SERVICE SHOP PARTS

Megagen Z Series Generators Spec Sheet

Z25, Z30, Z48, Z70 Operator's Manual

Z100 Operator's Manual

Z120, Z150 Operator's Manual

Description

Axiom Equipment Group offers industrial generators for sale, capable of delivering extreme operational flexibility and high efficiency for your industrial construction jobsite.

The Megagen Z Series is a range of high-quality, eco-friendly generator sets primarily used as sources of prime power. With robust design and long-lasting components, these generators are your reliable, easy-to-use solution for even the most demanding circumstances on site. They can also be controlled remotely via DSE controllers, providing you with maximum productivity and convenience for both commercial and residential applications. Whether you need generators for construction, mining, oil & gas, and more, we’ve got you covered.

Don’t settle for anything less – choose the Megagen Z Series generators to add to your rental fleet or to use for your next construction/industrial project!

Megagen Z Series Features

External fuel tank connectivity to maximize working autonomy
Trailer or skid mounted option
Remote control for generator start-up and shutdown
Superior soundproofing solutions
240V / 480V / 600V switchable
Deep Sea Electronics controller
3-way fuel valve for exterior fuel tank
Cold weather package
Master battery disconnect
Central, revolving lifting hook
110% secondary fluid containment
30% load bank/leveler
Warranty: 4yr / 4,000hr (whichever comes first)

Available generator sizes for sale include the Z20, Z30, Z48, Z70, Z100, Z120 and Z150 models. Certain features described above may not be available in other models.

Request a Quote

Technical Data		Z20	Z30	Z48	Z70	Z100	Z120	Z150
Engine		Kohler KDI1903M	Kohler KDI1903TCR	Kohler KDI2504TCR	Kohler KDI3404TCR	John Deere 4045HFG04	Cummins QSB5 – G12	Cummins QSB5 – G12
Gen End		Linz	Mecc Alte	Mecc Alte	Mecc Alte	Mecc Alte	Mecc Alte	Mecc Alte
Prime Output	kW (kVA)	16 (20)	24 (30)	38.4 (48)	56 (70)	80 (100)	96 (120)	120 (150)
Trailer Option		Yes	Yes	Yes	Yes	Yes	Yes	Yes
Voltage	V	240 / 480	240 / 480 / 600	240 / 480 / 600	240 / 480 / 600	240 / 480 / 600	240 / 480 / 600	240 / 480 / 600
Fluid Containment		110%	110%	110%	110%	110%	110%	110%
Receptacles		(2) 120V 20A Duplex (1) 120V / 240V 30A (1) 120V / 240V 50A	(2) 120V 20A (1) 120V / 240V 30A (2) 120V / 240V 50A	(2) 120V 20A (3) 120V / 240V 50A	(2) 120V 20A (3) 120V / 240V 50A	(2) 120V 20A (3) 120V / 240V 50A	(2) 120V 20A (3) 120V / 240V 50A	(2) 120V 20A (3) 120V / 240V 50A

A Megagen product
20 – 150 kVA generators
Highly efficient and offers operation flexibility
Highest quality workmanship.
Proven reliability and low life-cycle costs
Service and spare parts supply infrastructure
User-friendly control panel with full safety shut-down protection
Centre lift facility for easy lifting into hard to reach locations
Optional single and dual-axel trailer
Sound attenuated package provides quiet operation
Large fuel tank and external fuel tank connectivity offers longer run times
Digital controller provides easy to read LCD display
Durable features like stainless steel external hardware and automotive corrosion treatment of select body parts provide a long lasting, quality appearance
Factory installed customized options are available, including a fluid containment system, cold weather options and more.

Certain features may not be available in other models.
